Flanged barstock thermowell, US style TU54

Технические характеристики

Принцип измерения Литая термогильза
Характеристики / Применение Американские размеры
фланцевые присоединения к процессу
Соединительная головка внутренняя резьба: 1/2" NPT
Макс. стандартная погружная длина 24"
Присоединение к процессу Фланец
ASME 1" 150 RF (B16.5)
ASME 1" 300 RF (B16.5)
ASME 1" 600 RF (B16.5)
ASME 1" 900/1500 RF (B16.5)
ASME 1.5" 150 RF (B16.5)
ASME 1.5" 300 RF (B16.5)
ASME 1.5" 600 RF (B16.5)
ASME 1.5" 900/1500 RF (B16.5)
ASME 2" 150 RF (B16.5)
ASME 2" 300 RF (B16.5)
ASME 2" 600 RF (B16.5)
ASME 2" 900/1500 RF (B16.5)
ASME 3" 150 RF (B16.5)
ASME 3" 300 RF (B16.5)
ASME 3" 600 RF (B16.5)
Внутренний диаметр защитной гильзы 3/4"
7/8"
1 1/16"
Материал смачиваемых частей 316/ 316L
304
другие варианты доступны по запросу
Шероховатость поверхности смачиваемых частей (Ra) 32 мкм (0,80 мкдюйма)
Форма наконечника датчика прямой
суженный
ступенчатый
Диапазон температуры -200...700 °C (-328...1292 °F)
Макс. рабочее давление (статическое) 500 бар (7252 psi)
Макс. рабочее давление при температуре В зависимости от конфигурации

The robust thermowell is designed for use in demanding and safety relevant applications e.g. in the Chemical, Oil & Gas and Energy industry. Harsh environments, corrosive substances and highest pressures can be handled by the use of robust protection tubes and special materials.

Преимущества

  • Extension, immersion length and total length can be chosen according to process requirements
  • Modular configuration enable a use in all industrial processes with severe thermal and mechanical stresses
  • Fast response time with conical or stepped tip form

Область применения

Designed for use with resistance and thermocouple thermometers in industrial or heavy duty applications.

  • For increased protection requirements of the temperature sensor regarding physical and chemical effects
  • For use in pipes and containers or tanks
  • Ideally suited to all measuring points that require regular recalibration by replacing the insert in closed processes
